Capacitive Resistive Touch POS Monitor with VGA and USB port
Our Capacitive Resistive Touch POS Monitor features sharp 1024*768 display with wide viewing angles and 5ms instant touch response. It supports capacitive, resistive, infrared and SAW touch options, equipped with VGA, HDMI, DVI, USB and RS232 ports for flexible connection. This Capacitive Resistive Touch POS Monitor works smoothly with Windows, Android, Linux and Raspberry Pi systems, boasting a 50,000-hour service life and industrial dustproof, waterproof design for 24/7 continuous operation. Freely adjustable stand and VESA wall mounting meet diverse layout needs, ideal for supermarket checkout, restaurants, hospital service counters and industrial control terminals. Full matching accessories are included for easy installation right out of the box.
| Screen Basic Parameters | Screen size | 15″ |
| Standard Resolution | 1024*768 | |
| Number of Colors | 16.2M | |
| Brightness | 300cd/m2 | |
| Response time | 5ms | |
| View angle | Horizontal:160°Vertical:150° | |
| Contrast ratio | 1000:1 | |
| Duration | 50000 hours | |
| Touch Parameters | Touch model | multi point capacitive touch |
| Optional Touch Type | resistive touch, SAW, Infrared touch | |
| Touch validity | >1,000,000 times | |
| Touch response time | 5ms | |
| Touch interface | USB standard, RS232 optional | |
| Connector & Port | Video Connector | VGA standard for video signal (HDMI DVI option) |
| Touch Connector | USB standard (RS232 for touch option) | |
| Structure & Installation | Setup (optional) | 1. Wall brackets for wall-mounting, VESA 75mm&100mm2. Stable metal base to support the monitor |
| OSD control buttons | AUTO, +, POWER, -, MENU | |
| OSD adjustable items | brightness, contrast ratio, auto adjustment, phase, position, clock, Languages, function, Install, reset | |
| Power Spec | Power consumption | Max 30W |
| Frequency | 30~80KHz/60~75Hz | |
| Power supply | External Power Supply:100 to 240V (DC 12V 2.6A) | |
| Environment | Workable Temperature | -10 to 60°C |
| Storage temperature | -20 to 70°C | |
| Operate relative humidity | 20% to 80% | |
| Storage relative humidity | 10% to 90% | |
| Physical Size & Weight | Monitor Dimension | 352.8×280.3×43.2 mm |
| Net weight | 5.5 Kgs/pcs, include stable metal base | |
| Gross weight | 6.0 Kgs/pcs, include stable metal base | |
| Package Info | Package size | 4pcs in a carton, carton size:650450430mm, GW: 22KG/CTN |
| Standard Accessories | Accessories List | 1power supply1VGA/HDMI cable1* USB cable1* Touch pen1* User manual |
| Supported Systems | Operation system | Win7, Win8, Win10, Raspberry Pi, Android, Linux |
1. Product Basic Introduction
Our Capacitive Resistive Touch POS Monitor is a 15-inch touch screen specially made for commercial checkout and industrial use. It uses a clear 1024*768 screen with 300cd/m² brightness, so workers can read words clearly even in bright shops. This Capacitive Resistive Touch POS Monitor supports many touch types including multi-point capacitive touch, resistive touch and infrared touch, which fits different daily operation habits. Its service life reaches 50,000 hours, so shops can use it day after day without frequent breakdowns.
2. Smooth & Long-Lasting Touch Experience
This touch monitor has only 5ms touch response time, so every tap and slide reacts right away to cut waiting time for customers. It passes over 1,000,000 touch tests, meaning it can stand heavy tapping during peak shopping hours. The screen offers wide viewing angles: 160° horizontal and 150° vertical. Cashiers and managers can check data from different sides without color distortion, which greatly improves work efficiency in busy supermarkets and restaurants.
3. Flexible Connection & Multi-System Compatibility
Rich ports make this POS monitor easy to link all shop devices. It has standard VGA, optional HDMI and DVI for video output, plus USB and optional RS232 for touch signals. It works well with Windows 7/8/10, Android, Raspberry Pi and Linux systems, matching almost all common cash register software. The screen stand supports free angle adjustment, and it also fits VESA 75mm & 100mm wall brackets, letting you place it on counters or mount it on walls as you need.
4. Stable Industrial-Grade Practical Performance
It supports 24/7 non-stop operation with low power consumption (max 30W), saving your shop’s electricity cost. The monitor works normally from -10℃ to 60℃, and can be stored safely at -20℃ to 70℃. Its waterproof, dustproof and anti-interference design avoids damage from spilled drinks or dust in catering and retail spaces. Complete accessories including power adapter, signal cables and touch pen are packed together for quick installation, ready to use once you receive the goods.
